PRESSES FOR PIPES - HYDRAULIC PRESSES
14007
code
PLANT WELDING TRAITS / CONTINUOUS STAINLESS STEEL PIPES / DUPLEX / SUPER DUPLEX.
- DIAMETER BETWEEN 219.1 mm. and 1219.2 mm.
- THICKNESS up to: INOX 55 mm. - DUPLEX 45 mm. - SUPER-DUPLEX 35 mm.
- LENGTH up to 12 mt.
- Mast sliding complete with n° 6 hydraulic cylinders that allow you to close the flaps of the pipe and weld.
- The plant is designed for processing and saving of work cycles for various thicknesses of each tube diameter.
- The plant is complete with accessories that allow the handling of the pipes in complete autonomy, without the use of overhead cranes or external cranes.
- Complete loading system with automatic centering directly from the press brake.
- The structure designed with the mast slide allows the mounting of the system on an area of about 6 mt. x 15 mt.
- THICKNESS up to: INOX 55 mm. - DUPLEX 45 mm. - SUPER-DUPLEX 35 mm.
- LENGTH up to 12 mt.
- Mast sliding complete with n° 6 hydraulic cylinders that allow you to close the flaps of the pipe and weld.
- The plant is designed for processing and saving of work cycles for various thicknesses of each tube diameter.
- The plant is complete with accessories that allow the handling of the pipes in complete autonomy, without the use of overhead cranes or external cranes.
- Complete loading system with automatic centering directly from the press brake.
- The structure designed with the mast slide allows the mounting of the system on an area of about 6 mt. x 15 mt.
13001
code
AUTOMATIC PIPE CALIBRATION MACHINE.
- PRESS CALIBRATING MACHINE 4000TON TO CALIBRATE WELDED TUBES (MADE FROM METAL) FROM DIA. A 168MM DIA. 1250MM THICKNESS FROM 10MM TO 70MM STAINLESS STEEL
- DUPLEX
- SUPERDUPLEX
- POWER EXTRACTION 250TON
- LOAD HANDLING ON A ROLLER TUBE ANTERIOR AND POSTERIOR
- TRANSLATION AND ROTATION PIPE FULLY AUTOMATED WITHOUT A CRANE
- WITH POWER PULLER 50TON POSITION ON THE PLAN MOBILE
- MOVING OUT OF AUTOMATED MOULD DIE LOCK HYDRAULIC OPERATION UNLOADING / LOAD PRACTICABLE DIES IN 5 MINUTES WITH MAXIMUM DIE ALREADY PLACED
- TOTAL POWER ENGINE INSTALLED ABOUT 300KW
- ALL INSTALLED ENGINES ARE EQUIPPED WITH INVERTER THAT ALLOW AN ENERGY SAVING UP TO 50%.
- DUPLEX
- SUPERDUPLEX
- POWER EXTRACTION 250TON
- LOAD HANDLING ON A ROLLER TUBE ANTERIOR AND POSTERIOR
- TRANSLATION AND ROTATION PIPE FULLY AUTOMATED WITHOUT A CRANE
- WITH POWER PULLER 50TON POSITION ON THE PLAN MOBILE
- MOVING OUT OF AUTOMATED MOULD DIE LOCK HYDRAULIC OPERATION UNLOADING / LOAD PRACTICABLE DIES IN 5 MINUTES WITH MAXIMUM DIE ALREADY PLACED
- TOTAL POWER ENGINE INSTALLED ABOUT 300KW
- ALL INSTALLED ENGINES ARE EQUIPPED WITH INVERTER THAT ALLOW AN ENERGY SAVING UP TO 50%.
27005
code
PRESSES FOR STRAIGHTENING PLATE.
-SPAN BETWEEN PILLARS 2720 mm.
- PERFECT FOR WELDING PLATE WITH DIFFERENT THICKNESS AND MATERIAL UP TO 13500 mm, LONG (CUSTOM MADE)
- PRESSES WITH FLOATING CYLINDER AND SUPPORT
- PRESSES WITH COILS.
- PERFECT FOR WELDING PLATE WITH DIFFERENT THICKNESS AND MATERIAL UP TO 13500 mm, LONG (CUSTOM MADE)
- PRESSES WITH FLOATING CYLINDER AND SUPPORT
- PRESSES WITH COILS.
17030
code
STRUCTURE FOR HORIZONTAL 4-COLUMN PRESSES.
- POWER 50TON
- LIGHT BETWEEN COLUMNS 600x600mm.
- PRESS HAVING POSSIBILITY TO INCREASE THE LIGHT BETWEEN OPEN PLANS FROM 820mm TO 1570mm.
- PISTON STROKE 500mm.
10038
code
PRESS MOBILE SLIDING RAIL EXECUTION THE FIRST BENDING PIPE.
- POWER 800 ton.
- PERFECT FOR WORKING PIPES LENGTH OF 6 mt. TO 13 mt.
- PERFECT FOR WORKING PIPES LENGTH OF 6 mt. TO 13 mt.
28027
code
PRESS FOR SIMULTANEOUS 2 FOLDS.
- IDEAL FOR BENDING OF CALL ON TUBES WITH DIAMETER 10 "3/4 (858 mm. WIDTH PLATE) A D.48" (3830 mm. WIDTH PLATE) AND THICKNESS UP TO 60 mm. THIS ALLOWS YOU TO FOLD THE PRINCIPLE OF WORKING HALF THE TIME
- PRESS "COLUMNS 4"
- POWER 3000 ton. (N° 2 CYLINDERS 1500 ton. / CAD)
- LIGHT BETWEEN THE COLUMNS 4100X600 mm.
- LIGHT BETWEEN PLANS OPEN 1500 mm.v- STROKE OF HYDRAULIC CYLINDER 450 mm.
- SPEED 'DOWN / UP 200 mm/sec.
- SPEED 'MAX POWER AT WORK 10 mm/sec.
- VALVES EQUIPPED WITH CONTROL OF THE PRESS TO LEARNING SYSTEM AND FULL OF SAVING RECIPES, CYCLES TOTAL, PARTIAL CYCLES.
- PRESS "COLUMNS 4"
- POWER 3000 ton. (N° 2 CYLINDERS 1500 ton. / CAD)
- LIGHT BETWEEN THE COLUMNS 4100X600 mm.
- LIGHT BETWEEN PLANS OPEN 1500 mm.v- STROKE OF HYDRAULIC CYLINDER 450 mm.
- SPEED 'DOWN / UP 200 mm/sec.
- SPEED 'MAX POWER AT WORK 10 mm/sec.
- VALVES EQUIPPED WITH CONTROL OF THE PRESS TO LEARNING SYSTEM AND FULL OF SAVING RECIPES, CYCLES TOTAL, PARTIAL CYCLES.
29007
code
PRESS BRAKE - 4200 ton.
- PRESS WITH SPECIAL DRAWINGS 4200 ton.
- BENDING PRESS
- BENDING LENGTH 13000 mm.
- MACHINE LENGTH 14000 mm.
- MACHINE HEIGHT 6000 mm.
- UNMATCHED BENDING PRECISION
- HEMMING PRESS, LARGE SIZE BENDING PRESS, SYNCHRONIZED BENDING PRESS.
- BENDING PRESS
- BENDING LENGTH 13000 mm.
- MACHINE LENGTH 14000 mm.
- MACHINE HEIGHT 6000 mm.
- UNMATCHED BENDING PRECISION
- HEMMING PRESS, LARGE SIZE BENDING PRESS, SYNCHRONIZED BENDING PRESS.
12019
code
PRESS GOOSENECK 300 TON.
- SUITABLE FOR PROCESSING WELDING/CRANK HANDLE
- DIA MAX 762 mm. (30") MINIMUM 168 mm. (6-5/8")
- 450 mm. GROOVE
- 350 mm. STROKE SPEED UP/DOWN 28 mm/sec.
- SPEED WORKING 3 mm/sec.
- PRESS EQUIPPED WITH SIEMENS PLC.
- DIA MAX 762 mm. (30") MINIMUM 168 mm. (6-5/8")
- 450 mm. GROOVE
- 350 mm. STROKE SPEED UP/DOWN 28 mm/sec.
- SPEED WORKING 3 mm/sec.
- PRESS EQUIPPED WITH SIEMENS PLC.
28015
code
PRESSES FOR SPOT WELDING PIPES.
- EQUIPMENT USED TO WELD PIPES
- PRESSES FOR SPOT WELDING PIPES UP TO 50 mm THICK
- A SERIES OF CYLINDERS WITH 350 TON POWER THEY ALLOW PIPE TO BE CLOSED
- MINIMUM DIAMETER 160 mm, MAXIMUM DIAMETER 750 mm.
- MAXIMUM THICKNESS 50 mm FOR STAINLESS STEEL.
- PRESSES FOR SPOT WELDING PIPES UP TO 50 mm THICK
- A SERIES OF CYLINDERS WITH 350 TON POWER THEY ALLOW PIPE TO BE CLOSED
- MINIMUM DIAMETER 160 mm, MAXIMUM DIAMETER 750 mm.
- MAXIMUM THICKNESS 50 mm FOR STAINLESS STEEL.
28047
code
HYDRAULIC PIPE-SIZING PRESSES.
- PRESSES USED TO BEND PIPES “PILLAR” PRESS WITH “LINEAR” BEARINGS
- CYLINDER POWER 1500 Tons
- CYLINDER STROKE 800 mm.
- OPEN CYLINDER - WORK TABLE 1500 mm.
- OPERATOR’S SIDE SPAN 1470 mm.
- LATERAL OPERATOR’S SIDE SPAN 1050 mm.
- COMPLETE WITH EIGHT 20 Ton FEEDING CYLINDERS AND TWO 200 Ton FEEDING CYLINDERS
- USED FOR MANUFACTURING WELDED PIPES
- COMPLETE WITH AUTOMATIC MOULD CHANGING SYSTEM ON BOTH SIDES.
- CYLINDER POWER 1500 Tons
- CYLINDER STROKE 800 mm.
- OPEN CYLINDER - WORK TABLE 1500 mm.
- OPERATOR’S SIDE SPAN 1470 mm.
- LATERAL OPERATOR’S SIDE SPAN 1050 mm.
- COMPLETE WITH EIGHT 20 Ton FEEDING CYLINDERS AND TWO 200 Ton FEEDING CYLINDERS
- USED FOR MANUFACTURING WELDED PIPES
- COMPLETE WITH AUTOMATIC MOULD CHANGING SYSTEM ON BOTH SIDES.
27006
code
ROLLER PRESS - PRESSES FOR SPOT WELDING LOW THICKNESS PIPES.
- PERFECT FOR MANUFACTURING PIPES WITH MINIMUM 200 mm. DIAMETERS AND MAXIMUM 760 mm. DIAMETERS AND MAXIMUM THICKNESS OF 4 TO 6 mm. FOR STAINLESS STEEL
- PRESSES USED TO WELD HYDRAULIC PIPES.
- PRESSES USED TO WELD HYDRAULIC PIPES.
11002
code
-PRESS SYSTEM FOR CALIBRATION PIPES OF HIGH THICKNESS.
- POWER 3000 ton.
- IDEAL FOR CALIBRATION OF PIPES WITH A DIAMETER OF 168 mm. TO 1220 mm. LENGTH FROM A 6 mt. TO 13 mt.
- COMPLETE OF MOVING OF PIPE IN THE WORKING.
- IDEAL FOR CALIBRATION OF PIPES WITH A DIAMETER OF 168 mm. TO 1220 mm. LENGTH FROM A 6 mt. TO 13 mt.
- COMPLETE OF MOVING OF PIPE IN THE WORKING.
28002
code
MOULDS FOR PRESSES.
10019
code
PRESS TO TEST PIPES SEAL.
- POWER 800 ton.
- PERFECT FOR TEST OF RESISTANCE TO PRESSURE OF WELDING MADE ON LARGE THICKNESS PIPES
- FUNCTION: A HYDRAULIC SYSTEM PUT PRESSURE THE LIQUID (USUALLY WATER) INSIDE THE PIPE (PRESSURES UP TO BAR 800-1000), THE HYDRAULIC CYLINDER WITH POWER 800 ton.
- PERMITS TO MAINTAINING THE PRESSURE INSIDE THE TUBE FOR PERIOD FIXED.
- PERFECT FOR TEST OF RESISTANCE TO PRESSURE OF WELDING MADE ON LARGE THICKNESS PIPES
- FUNCTION: A HYDRAULIC SYSTEM PUT PRESSURE THE LIQUID (USUALLY WATER) INSIDE THE PIPE (PRESSURES UP TO BAR 800-1000), THE HYDRAULIC CYLINDER WITH POWER 800 ton.
- PERMITS TO MAINTAINING THE PRESSURE INSIDE THE TUBE FOR PERIOD FIXED.
25054
code
SYSTEM FORMING PIPES HOT.
- POWER 1500 ton.
- SPAN 2500x600x2600 mm.
- COLUMN DIAM. 400 mm.
- STROKE 1800 mm.
- SPEED DOWN / UP 100 mm/sec
- SPEED WORK 15 mm/sec
- POWER INSTALLATION 200 kW
- COMPLETE WITH 250 ton. LOWER BLANK HOLDER STROKE 2300 mm.
- COMPLETE WITH EXTERNALLY SLIDING BOLSTER TO CHANGE MOULDS TO 830X1350X110 mm.
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES LEVEL IVPROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.
- SPAN 2500x600x2600 mm.
- COLUMN DIAM. 400 mm.
- STROKE 1800 mm.
- SPEED DOWN / UP 100 mm/sec
- SPEED WORK 15 mm/sec
- POWER INSTALLATION 200 kW
- COMPLETE WITH 250 ton. LOWER BLANK HOLDER STROKE 2300 mm.
- COMPLETE WITH EXTERNALLY SLIDING BOLSTER TO CHANGE MOULDS TO 830X1350X110 mm.
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES LEVEL IVPROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.
