Front protection PHOTOELECTRIC BARRIERS
Rear protection CLOSED IN WORK ISLAND
Right side protection CLOSED IN WORK ISLAND
Left side protection CLOSED IN WORK ISLAND
Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 65 KW
Thrust force of the main cylinder 1500 Tons
Operator side horizontal light 2000 mm
Side horizontal light 1070 mm
Vertical light 1300 mm
Main cylinder stroke 700 mm
Height of the worktop from the ground 1050 mm
Lower worktop size 2000x1000 mm
Mobile worktop size 2000x1000 mm
Fast descent speed 200 mm / sec
Working speed 5-12 mm / sec
Fast ascent speed 200 mm / sec

Front protection PHOTOELECTRIC BARRIERS
Rear protection CLOSED IN WORK ISLAND
Right side protection CLOSED IN WORK ISLAND
Left side protection CLOSED IN WORK ISLAND
Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 60 KW
Thrust force of main cylinder 800 Tons
Operator side horizontal light 1335 mm
Side horizontal light 980 mm
Vertical light 1300 mm
Main cylinder stroke 800 mm
Height of the worktop from the ground 1000 mm
Dimension of the lower worktop 1300x1000 mm
Dimension of the mobile worktop 1300x1000 mm
Fast descent speed 200 mm / sec
Working speed 5-12 mm / sec
Fast ascent speed 200 mm / sec

Front protection of optical barriers
Screwed rear guard protection
Right side protection screwed carter
Left side protection screwed carter
Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 80 KW
Thrust force of the main cylinder 350 Tons
Operator side horizontal light 1000 mm
Side horizontal light 1000 mm
Vertical light 1,400 mm
Stroke of the main cylinder 1,000 mm
Height of the worktop from the ground 850 mm
Lower worktop size 1000x1000 mm
Mobile worktop size 1000x1000 mm
Fast descent speed 200 mm / sec
Working speed 20 mm / sec
Fast ascent speed 200 mm / sec

Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 65 KW
Thrust force of the main cylinder 1500 Tons
Operator side horizontal light 1850 mm
Side horizontal light 800x1200 mm
Vertical light 1200 mm
Main cylinder stroke 500 mm
Height of the worktop from the ground 1050 mm
Dimension of the lower worktop 1850x1500 mm
Dimension of the mobile worktop 1850x1500 mm
Fast descent speed 200 mm / sec
Working speed 5-12 mm / sec
Fast ascent speed 200 mm / sec

Front protection - PHOTOELECTRIC BARRIER
Rear protection - FIXED SCREWED HOUSINGS
Right side protection - CLOSED SIDE
Left side protection - CLOSED SIDE
Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 30 KW
Thrust force of main cylinder 300 Tons
Pushing force for sheet metal pressing cylinder 30 Tons
Operator side horizontal light 1340 mm
Vertical light 800 mm
Main cylinder stroke 700 mm
Stroke cylinder press sheet 300 mm
Height of the worktop from the ground 1200 mm
Lower worktop size 1200x800 mm
Mobile worktop size 1200x800 mm
Dimension of the worktop press plate 860x500 mm
Fast descent speed 100 mm / sec
Working speed 3 mm / sec
Fast ascent speed 100 mm / sec.
