- POWER 40TON
- INCOME 300MM
- LIGHT BETWEEN PISTON AND WORKTOP 400MM
- STROKE 300MM
- 100MM / SEC DESCENT SPEED
- WORKING SPEED 5MM / SEC
- 100MM / SEC RETURN SPEED
- COMPLETE WITH 10TON CORSA 100MM BLANK HOLDER
- ELECTRICAL EQUIPMENT EQUIPPED WITH THREE WORKING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC AND WITH ANTI-REPETITIVE BIMANUAL PUSH-BUTTON CONTROL
- COMPLETE ELECTRONIC INSTRUMENTATION BRAND "PROFACE" WITH SIEMENS PLC WITH POSSIBILITY TO SET UP UP / DOWN QUOTES / DESCENT PRESS AND PRESSURE AND PRESS PRESSURE PRESS
- COMPLETE WITH OPTICAL BARRIERS OF LEVEL IV BRAND "KEJENCE" ON THE OPERATOR'S SIDE AND FIXED PROTECTION IN THE NETWORK ON THE REMAINING SIDES PRESS

• 70TON POWER
• HOLE 360MM
• LIGHT BETWEEN PISTON AND WORKTOP 500MM
• PISTON STROKE 450MM
• DESCENT SPEED 100MM / SEC
• WORKING SPEED 5MM / SEC
• RETURN SPEED 100MM / SEC
• COMPLETE WITH 15TON STROKE 100MM STROKE
• ELECTRIC SYSTEM EQUIPPED WITH THREE WORKING CYCLES: MANUAL, SEMI-AUTOMATIC, AUTOMATIC AND WITH BIMANUAL ANTI-REPEAT PUSHBUTTON CONTROL
• PRESS COMPLETE WITH ELECTRONIC INSTRUMENTATION BRAND "PROFACE" WITH SIEMENS PLC WITH THE POSSIBILITY TO SET UP / DECELERATION / DESCENT ALTITUDES OF THE PRESS AND HOLDER AND PRESSURE SETTING
• COMPLETE WITH LEVEL IV OPTICAL BARRIERS BRAND "KEJENCE" ON THE OPERATOR SIDE AND FIXED NET PROTECTION ON THE REMAINING PRESS SIDES

-

• THE PARTICULARITY OF THIS PRESS IS THAT IT COMES FROM THE BOTTOM TOWARDS THE TOP AND ITS DIMENSIONS ARE THE FOLLOWING:
• POWER 100TON
• LIGHT BETWEEN THE COLUMNS 2300X1300MM
• LIGHT AMONG THE OPEN PLANS 1200MM
• LIGHT BETWEEN CLOSED WORKTOPS 150MM
• 600MM PISTON STROKE
• THIS PRESS HAS THE POSSIBILITY TO MOVE THE UPPER TOP IN DIFFERENT HEIGHTS UP TO A MAXIMUM OF 5 HOLES OF 150MM DISTANCE THEREFORE BRINGING THE LIGHT BETWEEN THE OPEN WORKTOPS MINIMUM TO 750MM INSTEAD OF 1200MM
• ASCENT / DESCENT SPEED 350MM / SEC
• WORKING SPEED 25MM / SEC
• OVERALL DIMENSIONS 3000X4500X3100MM (WIDTH X DEPTH X HEIGHT)
• WEIGHT 15.000KG

- POWER tonn. 50 - 500
- LIGHT NET between SHOULDERS mm. 855
- LIGHT NET between SHOULDER SIDE mm. 1320
- LIGHT between PLANS OPEN mm. 1010
- STROKE MOBILE PLAN mm. 700
- DISTANCE from LAND of the WORK PLAN mm. 1100
- SPEED CLOSED/OPEN mm./sec. 200
- SPEED WORK ADJUSTABLE mm./sec. 5 - 10

FEATURES EXTRACTION METAL AWARDS:
- POWER tonn. 40
- STROKE mm. 200

- ADJUSTABLE WORKING FORCE 50
- 1,000 tons
- USEFUL LIGHT AMONG THE OPERATOR SIDE COLUMNS 2100 mm.
- USEFUL LIGHT AMONG THE LATERAL COLUMNS 1100 mm.
- STROKE OF THE MOBILE FLOOR 1600 mm.
- LIGHT BETWEEN OPEN WORKTOPS 2500 mm.
- LIGHT BETWEEN WORKING PLANS CLOSED 900 mm.
- APPROXIMATION SPEED 300 mm / sec.
- DECELERATION SPEED 80 mm / sec.
- WORKING SPEED 0 - 10 mm / sec.
- RETURN SPEED 300 mm / sec.
- TANK WITH CAPACITY OF ABOUT 1600 lt.
- POWER OF MOTORS INSTALLED ABOUT 110 Kw.
- SIDES COMPLETELY CLOSED FOR SMOKE EXTRACTION.

- “4 COLUMN” PRESS
- POWER 2000 ton. SPAN 2000x2000x1800 mm. CYLINDER STROKE 1100 mm.
- SPEED 200/50/10-5/200 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION COMPLETE WITH EIGHT 20 ton. UPPER AND LOWER EXTRACTORS
- STROKE 100 mm.
- SELF LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES, WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND ON THE OPERATOR’S BACK SIDE AND WITH FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES
- PRESS WITH UPPER BLANK HOLDER CUSHION.

- “4 COLUMN” PRESS
- POWER 100 ton
- SPAN 2500x1350x2000 mm.
- STROKE 1250 mm.
- SPEED 400/15/400 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- SELF LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND ON THE OPERATOR’S BACK SIDE AND WITH FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES.

- “C-FRAME” PRESS - POWER 200 ton
- SPAN BETWEEN PISTON CENTRE AND PLATE LINE 1150 mm. (GROOVE)
- OPERATOR’S SIDE SPAN 1000 mm.
- SPAN BETWEEN OPEN SURFACES 500 mm.
- STROKE 500 mm.
- SPEED 28/3/28 mm/sec.
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- AND WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.

- “4 COLUMN” PRESS
- POWER 60 ton.
- SPAN 2000X700X1500 mm.
- STROKE 1000 mm.
- SPEED 200/10/200 mm/sec.
- EQUIPMENT WITH PROPORTIONAL SOLENOID VALVE WITH THREE MANUFACTURING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC AND WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES.

- “4 COLUMN” PRESS - POWER 40 ton
- SPAN 2200x520x850 mm.
- STROKE 350 mm.
- SPEED 70/40-20/70 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- COMPLETE WITH 10 ton BLANK HOLDER STROKE 100 mm.
- AND WITH 40 HOLES FOR 40 mm. DIAMETER ELECTRODES
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.

- PRESS EQUIPPED WITH TWO PISTONS WITH AN OVERALL POWER OF 500 ton
- SPAN 2000x1500x1200 mm.
- STROKE 1000 mm.
- SPEED 200/5-10/200 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION COMPLETE WITH 200 ton BLANK HOLDER STROKE 250 mm. AND WITH 50 HOLES FOR 40 mm. DIAMETER ELECTRODES AND WITH 3 MANUALLY ADJUSTABLE PRESSURE STAGES
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES - BIMANUAL PUSH-BUTTON CONTROL PANEL.
